REAR SUSPENSION.

SEGWAY
  • Manufacturer  SEGWAY
  • Product Code  SEGWAY_2_240_SX20T
Select MODEL:
Item nr. Pic. Part nr. Description Count in the table Cena za 1 ks Availability
1 BG008951-05532-000 CLIP 55  6 € 2,18 € 3
ON REQUEST
21 S10-D230050-0B0-00 LEFT MUDGUARD BRACKET Ⅰ  1 € 2,61 € 3
ON REQUEST
22 S10-D230060-0B0-00 RIGHT MUDGUARD BRACKET Ⅰ  1 € 2,61 € 3
ON REQUEST
23 S10-D230070-0B0-00 LEFT MUDGUARD BRACKET Ⅱ  1 € 2,61 € 3
ON REQUEST
24 S10-D230080-0B0-00 RIGHT MUDGUARD BRACKET Ⅱ  1 € 2,61 € 3
ON REQUEST
25 S10-D230090-0B0-00 ROCKER ARM MUDGUARD  2 € 10,44 € 13
ON REQUEST
26 S10-D230100-0B0-00 REAR UPPER TIE ROD ASSEMBLY  2 € 84,42 € 102
ON REQUEST
27 S10-D230200-0B0-00 REAR LOWER TIE ROD ASSEMBLY  2 € 88,44 € 107
ON REQUEST
28 S10-D230300-0B0-00 TOE CONTROL LEVER  2 € 90,86 € 110
ON REQUEST
29 S10-D260001-DB0-00 REAR BAR PLATE  2 € 2,36 € 3
ON REQUEST
30 S10-D260002-000-00 RAER BAR SLEEVE  4 € 2,18 € 3
ON REQUEST
31 S10-D261000-0B0-00 REAR STABILIZER BAR  1 € 92,50 € 112
ON REQUEST
32 S10-D262000-000-00 REAR STABILIZER BAR  2 € 48,06 € 58
ON REQUEST
33 S11-D250100-000-00 REAR LEFT SHOCK ABSORBER  1 € 2 574,22 € 3 115
ON REQUEST
34 S11-D250200-000-00 REAR RIGHT SHOCK ABSORBER  1 € 2 574,22 € 3 115
ON REQUEST
35 BOLT M6×20 (Item nr. 35) T03000007001 BOLT M6×20  16 € 2,18 € 3
IN STOCK
36 90° Connector pressure filling cup (Item nr. 36) T07000001007 90° Connector pressure filling cup  2 € 2,18 € 3
IN STOCK
20 S10-D230041-0B0-00 CONTROL LEVER PRESSURE PLATE  1 € 12,68 € 15
ON REQUEST
19 S10-D221011-0B0-00 RIGHT SCRAPER  1 € 5,31 € 6
ON REQUEST
18 S10-D221000-FB0-00 REAR RIGHT ARM, BLACK  1 € 405,30 € 490
ON REQUEST
2 BG057890-14070-ZA1 Hexagonal flange bolt M14 × 1.5 × 70  8 € 2,45 € 3
ON REQUEST
3 BG057890-14085-ZA1 HEX BOLT M14×1.5×85  6 € 3,11 € 4
ON REQUEST
4 BG057890-16080-ZA1 HEX BOLT M16×2.0×80  2 € 3,76 € 5
ON REQUEST
5 BG057890-16105-ZA1 HEX BOLT M16×2.0×105  4 € 4,51 € 5
ON REQUEST
6 BG061832-16200-ZA1 NUT M16×2.0  6 € 2,18 € 3
ON REQUEST
7 Bolt M8×16 (Item nr. 7) GBT005789014 Bolt M8×16  4 € 2,18 € 3
IN STOCK
8 HEXAGON FLANGE BOLT M10×1.25×20 (Item nr. 8) GBT005789025 HEXAGON FLANGE BOLT M10×1.25×20  4 € 2,18 € 3
IN STOCK
9 BG057890-12065-ZA1 Hexagonal flange bolt M12 × 1.25 × 65  2 € 2,18 € 3
ON REQUEST
10 BG057890-12070-ZA1 HEX BOLT M12×1.25×70  2 € 2,55 € 3
ON REQUEST
11 GBT061832008 NUT M14×1.5  16 € 2,18 € 3
ON REQUEST
12 NUT M12×1.25 (Item nr. 12) GBT061832010 NUT M12×1.25  4 € 2,18 € 3
IN STOCK
13 S10-D200010-000-00 JOINT BEARING  6 € 26,24 € 32
ON REQUEST
14 S10-D200011-000-00 REAR LEFT WHEEL AXLE SUPPORT  1 € 139,19 € 168
ON REQUEST
15 S10-D200021-000-00 REAR RIGHT WHEEL AXLE SUPPORT  1 € 139,19 € 168
ON REQUEST
16 S10-D211000-FB0-00 REAR LEFT ARM, BLACK  1 € 405,30 € 490
ON REQUEST
17 S10-D211011-0B0-00 LEFT SCRAPER  1 € 5,31 € 6
ON REQUEST
37 BG057890-14075-ZA1 HEX BOLT M14×1.5×75  2 € 2,18 € 3
ON REQUEST
Product Code SEGWAY_2_240_SX20T
PARTS CATEGORY: FRAME PARTS
Select BRAND: SEGWAY
Select TYPE: Villain SxS
Select MODEL: Villain SX20T
